The new SL00-R cable-extension sensor – the perfect combination of robustness, precision, and flexible mounting. With its durable stainless steel housing and compact design, the SL00-R offers diverse application possibilities in a wide range of industries. Learn more about the outstanding features and benefits of this innovative length measuring system and how it can optimize your applications.
at a glance
Key features and benefits
extremely robust
through V2A housing
maximum flexibility
through a modular design
Rope pull can be flexibly adjusted
by double-sided rotary encoder mounting
fully compatible
for all common Rotary Encoder types
versatile mounting options
without devices
additional freedom of direction
through 360° deflection pulley
Mounting options
Discover now
the special features
Click the tooltip buttons in the exploded view to learn more about the specific features of the SL00-R Draw Wire Sensor. Discover its high precision, robust design, and diverse application possibilities.
Compatibility and performance
The SL00-R-GS80 is perfectly matched to FSG Rotary Encoders, but is also compatible with standard encoders. All common signal outputs are supported.
Add a Title
The housing features drainage slots that channel away water and moisture. This prevents corrosion inside the housing and makes cleaning easier.
Robust housing
The durable housing made of V2A stainless steel (80 x 80 mm) offers a variety of mounting options for maximum flexibility during installation.
Improved return spring
A reinforced return spring (50% more than in the SL00 BASIC) reduces rope sag and increases robustness.
Durable rope & 360° pulley
Equipped with a robust 0.81 mm thick rope, which offers increased durability compared to conventional 0.55 mm ropes. A 360° pulley allows for additional directional freedom (optional).
Double-sided rotary encoder mounting
The SL00-R allows for the mounting of a Rotary Encoder on either side of the housing. The Draw Wire can be flexibly aligned to the left or right.
Mounting options
Fits perfectly for everyone
Application areas
The SL00-R cable-extension sensor is ideally suited for a wide range of industrial applications. It is used in construction machinery, vehicles and agricultural equipment, rail transport, as well as in automation and logistics. Wherever precise length measurements are required and the working environment demands robust and reliable sensors, the SL00-R demonstrates its strengths. Thanks to its compact design and high resistance, it delivers reliable measurement data even in challenging outdoor environments and offers excellent value for money.
Construction machinery
Ship
Rail transport
Mining
Agricultural technology
transport
logistics
medicine
Offshore
Mounting options
Mounting options
Mounting options
Gladly
You can also experience our products live at the
InnoTrans
September 22nd – 25th
Hall 27 | Booth 321
Do you have questions?
Contact us
Do you have questions about the SL00-R Draw Wire Sensor or need further information? Our technical sales team is happy to assist you. Please use the form below to contact us. We look forward to hearing from you and are happy to help.
mechanical
Details
housing scope
80 mm
max. measuring length
3,000 mm
trigger length
3,200 mm
drag to move
possible
Rotary Encoder variants
The SL00-R cable-operated sensor is optimally matched to FSG rotary encoders, especially these three encoder series. This ensures seamless integration and supports all common signal outputs, both analog and digital, enabling versatile use in various applications. Furthermore, the SL00-R is also compatible with standard encoders from other manufacturers, ensuring high flexibility in system integration.
available signal outputs
0-10V / 4-20mA
CAN / CANopen / CANopen juice
J1939
